NKK offers the industry's most extensive selection of off-the-shelf OLED and LCD programmable devices, referred to as SmartSwitches. NKK's SmartSwitch products combine a pushbutton or rocker switch with a graphic OLED or LCD display for a space-saving, simplified, multi-function device. A wide array of options are available from full-screen OLED pushbutton to compact LCD and display options. A complete line of development engineering kits are also available to enhance your design and application. The NKK SmartSwitch is a pushbutton switch that enables designers to create clear paths in complex decision making environments using intuitive and programmable custom menus. This enhanced decision-making capability provides a significant upgrade in the ease-of-use for operators giving more accurate guidance to complete their tasks. NKK’s SmartSwitch increases efficiency by reducing the time to train operators while delivering a significant reduction or elimination of operator errors. The SmartSwitch also has a wide viewing angle and can be seen from a distance allowing operators to quickly see any changes in their critical environments.

SMARTSWITCH Series Dec Kit Features:

• Assists with rapid prototyping and understanding the capabilities of the different SmartSwitch products.
• Contains all the necessary components to get you started using, testing and ultimately incorporating NKK Switches' SmartSwitch into your designs.
• The development kits come pre-programmed for demonstration. They can be reprogrammed by the user for demonstration or real-time application.
• NKK provides a free PC software (Universal Communicator 2015) for programming the development kits.
• IS-DEV-KIT-9, IS-DEV-KIT-8, IS-DEV-KIT-7, IS-DEV-KIT-7D, IS-DEV-KIT-6, IS-DEV-KIT-6C, IS-DEV-KIT-6D, IS-DEV-KIT-5, IS-DEV-KIT-5C, IS-DEV-KIT-5D, AT9946-93G, AT9946-091B, AT9946-099A, IS-S0108DEM, IS-CL04FL

Dev Kit 7 Features:

• IS-Dev Kit-7 controls two OLED (64x48) SmartSwitches (ISC15ANP4)
• Pushbutton functionality on each SmartSwitch
• RGB color OLED display with a resolution of 64x48 pixels
• IS-Dev Kit-7D controls two OLED (52x36) SmartDisplays (ISC01P)
• JB switches below SmartDisplays for control
• RGB color OLED display with a resolution of 52x36 pixels
• Power from USB or 9V power supply. (Power supply not included.)
• On board microSD Flash that can hold up to 65,536 images
• Adjustable audio feedback when a OLED switch is pressed
• Software control setting for 16 levels of brightness designed to extend the life of the OLED
• User programmable for images, attributes and set-ups

Real-time control by host:

• Commands to direct the controller to display any of 65,535 images to either of the two switches
• Commands to send characters so controller can create images for either of the two switches
• Commands to check various statuses of the controller
• Report switch activities to host
• Report the address of any new image displayed to host

Stand-alone operation:

• Set up the controller to function based on switch presses
• Set up the controller to function based on timer expiration
• Report switch activities to host
• Report the address of any new image displayed to host
• Communication via USB (57.6K, 1 start bit, 8 bit, 1 stop bit)
• Set the type of activity reports from the controller to host
• Power requirement: 5V to 12V at 180 mA max
• Controller board firmware can be customized based on customer requirements
